New Features in WCF 4.5 - Part 3

In my previous posts on this topic, I have explained about the following new features in Windows Communication Foundationv 4.5:
Now, here in this WCF Tutorial, I'll discuss the following new and exciting features in WCF v4.5.
  • ASP.NET Compatibility Mode Default Changed
  • BasicHttpsBinding

WCF - ASP.NET Compatibility Mode default changed

While working with previous version of Windows Communication Foundation, if we wanted that our WCF request should be treated in the same way as an ASP.NET request, for example, if we wanted to get access to HttpContext, we need to do a couple of steps to enable this feature in WCF. Because, by default, call to a WCF service bypass ASP.NET pipeline as opposite to normal ASMX web services.

Following are the steps we do to enable it: 1. In web.config, set aspNetCompatibilityEnabled to true.
<serviceHostingEnvironment aspNetCompatibilityEnabled="true" />

2. Add AspNetCompatibilityRequirements attribute to WCF Service with AspNetCompatibilityRequirementsMode set to either Allowed or Required.
[AspNetCompatibilityRequirements(RequirementsMode = AspNetCompatibilityRequirementsMode.Required)]
public class MyWCFService : IMyWCFService


In WCF 4.5, AspNetCompatibilityRequirementsAttribute is, by default, set to "Allowed". So, giving complete control to features in ASP.NET pipeline.

WCF - BasicHttpsBinding

As we have already discussed in earlier parts of this WCF 4.5 Tutorial series that v4.5 has simplified a lot of things for the developers. This new BasicHttpsBinding does the same for us.
BasicHttpBinding is available in Windows Communication Foundation since initial versions. The new BasicHttpsBinding is almost similar to BasicHttpBinding with following two exceptions:
  • Default Security mode = Transport
  • Default Client Credential Type = None
So, earlier with BasicHttpBinding, declaring transport security based endpoint in WCF is as follows:
           <binding name="BindingConfig1">
                 <security mode="Transport" />
        <service name="MyWCFService">
             <endpoint address=""

But using WCF 4.5, the same above configuration is simplified as follows:
         <service name="MyWCFService">
               <endpoint address=""

Definitely, this cool features simplifies configuration and increases WCF developer productivity.
